460PBSWI
$NZD1600 - $NZD1600
Please note, site orders are made via credit card. Please contact sales@techstep.co.nz if you require support to purchase directly.
Product Description
Connect your Profibus master devices to a web interface
The 460PBSWI moves data between Profibus Masters and Web Interface devices. Best of all, the product is made in the USA and comes with 5-year warranty.
How Do I Use the 460PBSWI in My Application?
First, you configure the 460PBSWI using the browser-based configuration pages. You’ll identify the data slots. Once that’s complete, you’ll map, name and group the data to be presented as XML or JSON files. Your application can issue standard HTTP GET or POST instructions to move data into your application. Up to 10 input and 10 output slots can be configured. SSL transport layer security protects the data moving from your operations network to the cloud.
Why Use Real Time Automation as a Gateway Supplier?
While there are certainly other companies offering protocol gateways, there is no one who provides the level of support and service that you receive from RTA.
When you call, a live person answers the phone. When you talk with sales, you will get honest answers and recommendations. When you get support, it is from an engineer who had a hand in the product’s development, and support doesn’t require a ticket or 24-hour wait.
Profibus Slave Features
Object Model: 10 Slots in each directionSlot Size: 2, 4, 8, 16, 24, 32 Bytes
Data Representation: int8, int16, int32, int64, uint8, uint16, uint32, uint64, Float, Double, binary8, binary 16, binary 32, Short String
Total Data Supported: 244 Bytes in each direction
Maximum Profibus DP Connections: 1
Web Interface Features
Max Web Interface Connections: 1 (Gateway acting as Client) / Unlimited (Gateway acting as Server)Encodings: JSON, XML
Proxy Support: HTTP, SOCKS5 for Client
Maximum Number of Input Data Points: 1000 JSON Fields or 1000 XML Tags
Maximum Number of Output Data Points: 1000 JSON Fields or 1000 XML Tags
HTTP Services: Client: POST only; Server: GET and POST
Related Resources
OUR COMPLETE SATISFACTION GUARANTEE
Every RTA gateway provided by Tech Step comes with a 30 DAY 100% SATISFACTION GUARANTEE. If an application falls through, you find an alternative, or if you just wanted to try out a gateway -if for any reason you are not 100% satisfied, you can return the unit for a refund of the purchase price.
In addition, every gateway comes with a 5 YEAR BETTER THAN INSURANCE WARRANTY.You will never have to blame the dog for eating your gateway. We don’t care if you let out the magic black smoke confusing AC with DC power or if you run the unit over with a forklift. Even if you break it, we will fix it or replace it at no cost for 5 years after purchase. That’s the RTA way.
